PARTS AND ACCESSORIES
FUSION Remote Display Kit
Improve usability and reduce manual controls by mounting this FUSION controller display on the door of your enclosure.
Auxiliary I/O Card
Provides extra digital inputs and outputs for alarms or overrides, and analog retransmit channels to send real-time operational data (like load voltage or current) directly to a PLC or control system.
Product Information
Retransmit:
- 2 Analog output channels
- Scalable 0-10 Vdc or 0-20 mA with up to 15 Vdc compliance voltage
- Each channel may be assigned either the RMS or AVG value of the load voltage, load current, or true instantaneous load power.
Digital I/O:
- 2 Digital Inputs (TTL compatible, pull up to 5 V through a 10 kOhm resistor)
- 2 Digital Outputs (Relay driver transistor-based, open collector that sinks up to 48 VDC at 150 mA)
Downloads
| Manuals and Brochures | |
|---|---|
| FUSION Accessories List | Download |
